AZES STANDARD
Ibanez builds guitars for players of all levels—from beginners to the most demanding masters of the instrument. Regardless of price, Ibanez always strives to offer the absolute best sound, style, and playability in its class. The Standard series incorporates all the staples the Ibanez brand is famous for, such as fast necks, floating trems, and high-octane distortion in a package that is available and accessible to most players.
Wood grain may vary slightly from product photos shown.
SPECS
- Neck Type: AZES / Maple Neck
- Top/Back/Body: Poplar
- Fretboard: Jatoba Fretboard / White Dot Inlay
- Frets: Medium
- Number of Frets: 22
- Bridge: T106 Bridge w/Comfort Round Steel Saddles
- String Spacing: 10.5mm
- Neck Pickup: Essentials (S) Neck Pickup (Passive/Ceramic)
- Middle Pickup: Essentials (S) Middle Pickup (Passive/Ceramic)
- Bridge Pickup: Accord (H) Bridge Pickup (Passive/Ceramic)
- Factory Tuning: 1E,2B,3G,4D,5A,6E
- String Gauge: .010/.013/.017/.026/.036/.046
- Hardware Color: Chrome
NECK DIMENSIONS
- Scale Length: 635mm/25"
- Width at Nut: 42mm
- Width at 22F: 56.4mm
- Thickness at 1F: 20.5mm
- Thickness at 12F: 22.5mm
- Radius: 250mmR
CONTROLS
- Volume
- Tone
- 5-Way Pickup Selector
- Alter Switch
SWITCHING SYSTEM
When the alter switch is in neck position, two hum tap mode is on. When the alter switch is in bridge position, two hum tap mode is off. Two hum tap mode means the neck and middle pickups are wired in series and functioning as a humbucker. When two hum tap mode is off and the pickup selector switch is in neck position, neck pickup is selected. When the switch is in between neck and center position, neck and center pickups are selected. When the switch is in center position, center position is selected. When the switch is in between center and bridge position, center pickup and neck side of the bridge pickup are selected. When the switch is in bridge position, the bridge pickup is selected. When two hum tap mode is on and the pickup selector switch is in neck position, the neck and center pickups are selected and they are in series. When the switch is in between neck and center position the neck pickup and bridge side of the bridge pickup are selected. When the switch is in center position, neck, center, and bridge pickups are selected; the neck and center pickups are in series mode. When the switch is in between center and bridge position, the neck side of the bridge pickup is selected. When the switch is in bridge position, the bridge pickup is selected.
SKU: AZES40PRB
