Details

SPECS

• Neck Type: AM Expressionist / 3pc Nyatoh/Maple / Set-in Neck

• Top/Back/Side: Linden

• Fretboard: Bound Macassar Ebony / Abalone Dot Inlay

• Fret: Medium Frets

• Number of Frets: 22

• Bridge: Gibraltar Performer Bridge

• String Space: 10.5mm

• Tailpiece: VT06 Tailpiece

• Neck Pickup: Super 58 (H) Neck Pickup (Passive/Alnico)

• Bridge Pickup: Super 58 (H) Bridge Pickup (Passive/Alnico)

• Factory Tuning: 1E,2B,3G,4D,5A,6E

• String Gauge: .010/.013/.017/.030/.042/.052

• Nut: Plastic Nut

• Hardware Color: Gold


• Scale: 628mm

• Width at Nut: 43mm

• Width at 22F: 57mm

• Thickness at 1F: 21mm

• Thickness at 9F: 24mm

• Radius: 305mmR


• Length: 17 5/8"

• Width: 14 1/2"

• Max Depth: 2 5/8"


• 3-Way Pickup Selector:

  • Neck Postion: Neck Pickup

  • Center Position: Neck & Bridge Pickups

  • Bridge Position: Bridge Pickup

• Tri-Sound Switch:

  • Position 1: Neck Humbucker is Parallel Connected

  • Position 2: Neck Pickup in Single Coil

  • Position 3: Neck Pickup in Humbucker


• Neck Volume

• Neck Tone

• Bridge Volume

• Bridge Tone

• 3-Way Pickup Selector

• Tri-Sound Neck Pickup Switch
